Blackmagic Design SmartScope Duo 4K

The SmartScope Duo 4K looks like Blackmagic's SmartView Duo but adds independent waveform monitoring to each of its two displays, so you can put a picture on one screen and a scope — waveform, vectorscope, RGB parade, YUV parade, histogram, or audio phase — on the other, or run scopes on both simultaneously. Each monitor works independently, auto-switching between SD, HD, and 6G-SDI, and a 9-pin D connector adds tally support for on-air status.

• Two independent scope/picture displays: waveform, vectorscope, RGB parade, YUV parade, histogram, and audio phase/level views, selectable per monitor.
• Auto SD/HD/6G-SDI switching: 10-bit loop-through SDI output, 16 channels of embedded audio in/out.
• Broad format support: SD, HD, 2K DCI, and Ultra HD up to 2160p30; SMPTE 259M/292M/296M/372M/424M/425M compliant.
• 3RU rack mount: under 20W power consumption, USB 2.0 for updates and Ethernet for configuration.
• Includes power supply and configuration software: for Mac and Windows, with a 12-month limited warranty.
